Character：
1. The heating tube is made of stainless steel imported from Taiwan. The heating tube is completely immersed in the heat-conducting oil to heat up, the heating rate is fast, and the energy saving is more than 15%.
2. Pneumatic pressurizing device, which can be adjusted according to different materials, the transfer speed is faster and the color is more vivid.
3. The inflation shaft retracting function, the paper feeding/distributing is parallel and accurate without offset, and the delivery is tighter and more.
4. The felt strip is separated, adopts the synchronous rod adjustment, and has a pressure balance rod to ensure that the pressure between the felt belt and the heating cylinder is consistent.
5. The machine peripherals are independent of the fuel tank, and it is more convenient to add heat transfer oil.
|
Model |
PT-C801 |
PT-C802 |
PT-C803 |
PT-C804 |
|
Drum Diameter(mm) |
220 |
270 |
370 |
420 |
|
Heating Method |
Oil-based heating |
Oil-based heating |
Oil-based heating |
Oil-based heating |
|
Blanket width(mm) |
1200 |
1700 |
1800 |
1800 |
|
Voltage |
220V/50Hz |
220V/50Hz |
380V/50HZ |
380V/50HZ |
|
Table Length(mm) |
1300 |
1300 |
1510 |
2000 |
|
Max working speed (m/h) |
30-50 |
40-60 |
50-80 |
60-100 |
